Quantities are limited. No one else has these, be the first!
New with Detailed
instructions, wire ties to make your installation
Direct Cord with Round MUTE Button accessory is a unique power cord with a convenient
MUTE BUTTON right within arms reach!
Tired of dangling power cords? Our
direct cords eliminate the bulky dangling power cords that hang over your
dashboard and over your rearview mirror.
Our instructions are very detailed
and installation is very simple.
We usually ship the same day so you get your
order with lightning fast shipping!
a Direct Cord with Round MUTE button?
The Direct Wire Cord with
button is an optional accessory that allows you to connect your radar detector
directly to your fuse block or other 12-volt source
(leaving your lighter socket free
for other uses) and provides
a MUTE button to be placed closer to you.
The Direct Cord with Round
button is approximately 8
feet long, with the MUTE
button on a cord that about 4 feet long and connected at the built-in
end of the cord so you can place it within arms reach.
It's the perfect addition for any
car when reaching the detector's mute button on the windshield is a stretch.
Normally comes with a T - Tap
to connect to a power wire source like below.
Just wrap the t-tap onto the wire and pinch
with a pair of pliers, then you just connect the red wire to the t-tap.
Wrap t- tap onto wire and squeeze with pliers
Insert connector onto the t-tap for power
1. Blade Fuse Tap
to connect to a blade fuse
in the fuse box
2. Mini Blade Fuse Tap
to connect to a mini blade fuse
in the fuse box.
Here is a comparison of
the blade fuse on the left and the mini blade fuse on the right
Now you can wire directly to your
fuse box and eliminate dangling power cords.
Our power cords will allow your radar detector to be hard
wired to your vehicle very easily. If you do change vehicles, simply unplug the
red wire from the T-tap connector or the Fuse tap, and unhook the black ground
This kit will work on the below detectors that uses the "Modular" type power plug.
9500i GPS, 9500i,
Solo S2, Solo S3
Passport 8500 X50 Blue or Red, Passport 8500, Passport 7500,
ROUND MUTE BUTTON:
the cord for the mute button is about 4 feet long. Figure out where you would
like to mount your mute button. The round mute button needs a hole that is
approximately 1/4" or 6.5mm to mount. Try to test drill a hole onto an extra
piece of plastic or wood that is not needed to make sure the hole is
sure the chosen mounting location is either 1/8" or 2.5mm thickness or less.
Round mute button will not screw into a hole if the mounting surface is any
the nut from the round mute button. Place the round mute button through the
hole from behind with the lock washer on it or after the mounting hole. The
lock washer is the round washer with the slit in it, it is slightly curved up
from each end. The lock washer is needed so the nut will not loosen from
vibration. Hold the round mute button with one hand and hand tighten the nut
onto the round mute button on the front side of the mounting hole. Finally
tighten with a pair of needle nose pliers just until the lock washer flattens.
OR You could also add (2)TWO L.E.D.
for your Direct Cord with Mute Button.
L.E.D. turns on when your radar detector is on, turns off when your
radar detector is off.
L.E.D. blinks when in alert mode and is off when not in use.
Comes on a four foot cord (for each
L.E.D.) so you can place it almost anywhere.
Order with the Mute Button Cord and
we will install it on the cord for you.
Red power L.E.D. for
New Direct Cord with built-in
Mute Button kit
instructions to make your installation a breeze
Wire ties to
make your installation neat
with a T - Tap
to connect to a power wire source.
If you need a Fuse tap, just let us know which one you
would like and we'll replace the T-Tap in your order.
1. Blade Fuse
2. Mini Blade
to connect to fuse in the fuse box very easily.
Make sure you get a 1 year limited
warranty at no charge.
Delivery Confirmation to track your
order. (available in most cases)
